CS1210M/R48A

Megapixel Cooled MWIR Detector

Megapixel clarity · Long range and wide field | A core driver for high-end civil sensing and industrial NDT.

CS1210M/R48A product photograph
Resolution1280 × 1024
Pixel pitch10 μm
Spectral range3.7–4.8 μm
NETD≤22 mK
Frame rate50 / 100 Hz

01 / Product introduction

Product introduction

Built on type-II superlattice (T2SL) technology with a 10 μm small-pixel package, this detector delivers megapixel-class 1280 × 1024 infrared imaging. The small pixel raises system resolution and field of view while allowing a smaller, shorter lens — reducing the size, weight and cost of the complete system. It is built for long-range civil surveillance, high-end UAV payloads, industrial chip inspection and petrochemical patrol work.

02 / Core application scenarios

Core application scenarios

01
High-end civil UAVs and unmanned systemsHigh-altitude forest-fire patrol, long-range ecological protection, wildlife monitoring and search-and-rescue payloads.
02
Industrial NDT and semiconductor researchMicron-scale thermal-defect analysis of wafers and chips, material thermal-stress testing and precision laboratory spectroscopy.
03
Power-line and pipeline inspectionLong-range fault screening on high-voltage grids, aerial patrol of long-distance oil and gas pipelines and rapid thermal-anomaly identification.
04
Smart perimeter and traffic monitoringAirport perimeter protection, port and waterway navigation safety, and long-range night surveillance of large industrial parks.

03 / Core advantages

Core advantages

01
Megapixel detailA 1280 × 1024 array on a 10 μm pitch multiplies detail resolution, capturing small distant targets and minute hot spots with ease.
02
High sensitivity and consistencyAn NETD of ≤22 mK, operability of ≥99.7% and response non-uniformity of ≤8% present a smooth, high-contrast thermal picture.
03
Compact-optics compatibilityThe 10 μm pixel pitch substantially reduces front-end focal length and lens diameter, lowering optical cost and total system weight.
04
Stable continuous operationSteady-state consumption of ≤6 W supports round-the-clock monitoring in continuously powered installations.

04 / Core technical specifications

Core technical specifications

Resolution
1280 × 1024
Pixel pitch
10 μm
Spectral range
3.7–4.8 μm
NETD
≤22 mK
Frame rate
50 / 100 Hz
F-number
F/2 / F/4
Cooldown
≤6.5 min
Power
≤17 W peak
Weight
≤580 g

04 / Project integration

Integration essentials

F-number
F/2 / F/4
Cooldown
≤6.5 min
Power
≤17 W peak
Weight
≤580 g
