CS0615M/R26A

Cooled MWIR Detector

Exceptional thermal sensitivity · Industrial-grade precision imaging | A sensing core for high-end civil inspection and gas detection.

CS0615M/R26A product photograph
Resolution640 × 512
Pixel pitch15 μm
Spectral range3.7–4.8 μm
NETD≤18 mK
Frame rate50 / 100 Hz

01 / Product introduction

Product introduction

Built on type-II superlattice (T2SL) technology and a miniature cooling assembly, this 640 × 512 / 15 μm cooled detector combines very high thermal sensitivity, low power draw and excellent image uniformity. Its accurate response across the mid-wave infrared band makes it purpose-built for high-end civil imaging systems in industrial non-destructive testing, petrochemical gas-leak monitoring, power-line inspection and smart security.

02 / Core application scenarios

Core application scenarios

01
Petrochemical and environmental monitoringPrecision temperature measurement inside industrial furnaces, plus infrared detection of VOCs and oil-and-gas leaks.
02
Industrial NDT and researchThermal-defect inspection of semiconductor chips, material thermal-stress analysis and laboratory spectral imaging.
03
Power-line inspection and special equipmentLocating thermal faults in high-voltage assets and 24-hour safety monitoring of kilns and high-temperature plant.
04
Civil unmanned systems and smart securityAirborne electro-optical payloads for civil UAVs, perimeter protection and intelligent-traffic imaging.

03 / Core advantages

Core advantages

01
Very high thermal sensitivityAn NETD of ≤18 mK resolves minute temperature differences, keeping fine thermal detail clearly visible.
02
Excellent image uniformityAn operability of ≥99.7% and response non-uniformity of ≤5% deliver an even, clean image across the full array.
03
Fast cooldown and low powerCooldown completes in ≤4 min with steady-state consumption of only ≤4 W, suited to continuous long-duration operation.
04
Compact and integration-readyA standardised interface and lightweight package support rapid replacement and secondary development.

04 / Core technical specifications

Core technical specifications

Resolution
640 × 512
Pixel pitch
15 μm
Spectral range
3.7–4.8 μm
NETD
≤18 mK
Frame rate
50 / 100 Hz
F-number
F/2 / F/4 / F/5.5
Cooldown
≤4 min
Power
≤16 W peak
Weight
≤350 g

04 / Project integration

Integration essentials

F-number
F/2 / F/4 / F/5.5
Cooldown
≤4 min
Power
≤16 W peak
Weight
≤350 g
